ANSI/ASME B16.9/B16.11 - Monel 400, K500 Forged Pipe Fittings

Monel 400 stub end, ASTM B564 Monel 400 pipe fittings, Monel 400 Tee, ANSI B16.9 Monel 400 forged pipe fitting, UNS N04400, Monel k500 Reducer, Monel 400 Flanges, Monel k500 elbow, Monel 400 pipe bends, ASTM B164 Monel 400 Round Bars, ASTM B165 Monel pipe fittings, ASME B16.11 Monel 400 pipe fittings, ASTM B366 Monel K500 pipe

JF Engineering is stockiest, maker and maker of Monel Pipe Fittings which have exceptional quality completing and compel for long life, high weight and zero imperfections.

In both the domestic market and international countries, we ensured the fast delivery of Monel Pipe Fittings. The main reason is that our facilities are excellent for storing finished and semi-finished goods. These products are produced following customer requirements. Packaged in wooden corrugated boxes, the Monel piped fittings are foiled in plastic wraps and bubble wraps. We offer standard and non-standard sizes, these fittings are produced according to customer requirements. The product range has various fitting elements for the easy and rapid installation of pipelines and is designed to comply with industry standards. The pipe fittings are made of Monel superior grades which are suitable in valves, industrial thermal exchangers, and pumps. Under international standards, we offer a full range of Monel forging fittings in different sizes, forms, and dimensions. In high temperature and pressure applications, these fittings offer stronger corrosion resistance. Monel K500 is Nickel-Copper and offers excellent resistance properties with the addition of titanium and aluminum. This alloy is highly resistant to alkaline and sea waters.

Special features of Monel Pipe Fittings:
  • Brilliant resistance to sulphuric acid
  • Great Mechanical Properties
  • Weak resistance with oxidizing substance
  • Can be easily welded and soldered
Special Applications:
  • Heat Exchangers
  • Oil Refineries
  • Chemical Process
  • Hydro carbon Process

Key Properties of Alloy 400/Monel Pipe Fittings and Flanges

  • Good mechanical properties
  • Strong resistance to sulfuric and hydrofluoric acids
  • Good resistance to chloride in stress corrosion cracking
  • High resistance to alkaline and acid salts
  • Weak resistance with oxidizing acid salts such as ferric chloride
  • Can be easily welded and soldered

Applications – Monel Pipe Fittings and Flanges

  • Valves
  • Heat Exchangers
  • Oil refineries
  • Chemical process industries
  • Hydro carbon processing

Monel Pipe Fittings Production Range

Specification ASTM B366, ASME B366, ASTM B564, ASME SB564, ASTM B865, ASME SB865
Grade Alloy 400/Monel 400/UNS N04400/2.4360, Alloy K-500/Monel K-500/UNS N05500/2.4361
Type Seamless / Welded / Fabricated
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Range ½”NB to 24”NB in Sch 10s, 40s, 80s, 160s, XXS.
Dimensions ANSI/ASME B16.9, B16.28, MSS-SP-43.

Buttweld Monel Pipe Fittings

Seamless/ Welded 100% Radiography Tested

Products Size
Monel 400 Elbows – Long Radius Monel 400 Stub Ends

Sizes 1/2″ – 24″

Monel 400 Elbows – Short Radius Monel 400 Crosses
Monel 400 Reducing Elbows Monel 400 Reducing Crosses
Monel 400 45° Elbows Monel 400 180° LR Return Bends
Monel 400 Tees Monel 400 180° SR Return Bends
Monel 400 Reducing Tees Monel 400 Pipe Bends / Piggable Bends
Monel 400 Reducers Monel 400 Couplings
Monel 400 Concentric Reducers Monel 400 Nickel Pipe Nipples
Monel 400 Eccentric Reducers Monel 400 Forged/Plate Cut Rings
Monel 400 3D Elbow Monel 400 End Caps
Monel 400 5D Elbow Monel 400 Forged / Plate Circles

High Pressure Forged Monel Pipe Fittings

Threaded and Socket Weld Pipe Fittings

Products Size
Monel 90° Elbows Monel Couplings

Sizes 1/8″ – 4″

Pressure Ratings –
2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Monel 45° Elbows Monel Reducers
Monel Street Elbows Monel Inserts
Monel Tees Monel Caps
Monel Crosses Monel Unions

Monel Flanges

Forged and Plate Flanges

Specification ASTM / ASME SB 564 / 160 / 472
UNS Grade Monel 400 (UNS No. N04400), Monel K500 (UNS No. N05500).
Standard ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size ½” to 36″
Dimensions ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Class / Pressure 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Product Size
Monel Slip-On Flanges Monel Threaded Flanges

1/8″ – 36″

Raised Face or Flat Face

Monel Weld Neck Flanges Monel Socket Weld Flanges
Monel Blind Flanges Monel Reducing Flanges
Monel Lap Joint Flanges Monel Plate Flanges

Marking & Packing

Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All fittings and flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.

Quality Assurance

At JF Engineering Products LLP, all fittings and flanges are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.

Test Certificates: Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
