ANSI/ASMI B16.5 Spacer Blind Flanges - Stainless Steel ASTM A182 316L, 317L

Spacer Blind Flanges

PED Approved Spacer Blind Flanges Exporter, Duplex 2205 Spacer Blind Flanges Manufacturer, UNS S30400 Spacer Blind Flanges Manufacturer, Inconel 625 Spacer Blind Flanges Exporter, ASTM A105 Spacer Blind Flanges , ASTM A105 Spacer Blind Flanges Stockist, UNS S30400 Spacer Blind Flanges , PED Approved Spacer Blind Flanges

Alloy 20 Spacer Blind Flanges Manufacturer, Monel 400 Spacer Blind Flanges , ASTM A182 SS 304 Spacer Blind Flanges , Nickel 200 Spacer Blind Flanges , 316 Stainless Steel Spacer Blind Flanges Stockist, UNS S32750 Spacer Blind Flanges , Duplex 2205 Spacer Blind Flanges , ASTM A182 SS 304 Spacer Blind Flanges Supplier.

Specification - ASME B16.5 Spacer Blind Flanges
Size: 1/2"NB TO 24"NB IN
Class: 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN Standard ND-6,10, 16, 25, 40 Etc.
Materials: Monel :
Grade: Monel 400, Monel K500, Monel R-405
Nickel :
Grade: Nickel 200, Nickel 201
Inconel :
Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718
Incoloy :
Grade: Incoloy 800, Inconel 800H, 800HT
Hastalloy :
Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X
Titanium :
Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11
Stainless Steel :
Grade: ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L
Carbon Steel :
Grade: ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8
Duplex Steel:
Grade: ASTM / ASME A/SA 182 UNS F44, F45, F51, F53, F55, F60, F61
Alloy Steel:
Grade : ASTM A182 F1, F5, F9, F11, F22, F91
Value Added Service: CNC Machine, Customized Flanges
Coating/Surface Treatment: Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized

Dimension - ASME B16.5 Spacer Blind Flanges
Nominal Bore Spacer Blind Flanges Dia.
(D)
Thick.
(E)
Dia.
(B)
Dia.
(A)
Height
(H)
Nbr Holes Dia.
(C)
1/2″ 90 11.2 30 22.9 16 4 15.87 60.3
3/4″ 100 12.7 38 28.2 16 4 15.87 69.9
1″ 110 14.3 49 34.9 17 4 15.87 79.4
1 1/4″ 115 15.9 59 43.7 21 4 15.87 88.9
1 1/2″ 125 17.5 65 50.0 22 4 15.87 98.4
2″ 150 20.7 78 62.5 25 4 19.05 120.7
2 1/2″ 180 22.3 90 75.4 29 4 19.05 139.7
3″ 190 23.9 108 91.4 30 4 19.05 152.4
3 1/2″ 215 23.9 122 104.1 32 8 19.05 177.8
4″ 230 23.9 135 116.8 33 8 19.05 190.5
5″ 255 23.9 164 144.4 36 8 22.22 215.9
6″ 280 25.4 192 171.4 40 8 22.22 241.3
8″ 345 28.6 246 222.2 44 8 22.22 298.5
10″ 405 30.2 305 277.4 49 12 25.40 362.0
12″ 485 31.8 365 328.2 56 12 25.40 431.8
14″ 535 35.0 400 360.2 79 12 28.57 476.3
16″ 595 36.6 457 411.2 87 16 28.57 539.8
18″ 635 39.7 505 462.3 97 16 31.75 577.9
20″ 700 42.9 559 514.4 103 20 31.75 635.0
24″ 815 47.7 663 616.0 111 20 34.92 749.3
Weight Chart Of Spacer Blind Flanges
Nominal Size Diameter Flange I.D No. of holes Flange Dia Thk of Flange Dia of Bolt Circle Dia of Bolt Holes Approx.Weight
DN ISO DIN D5 BN D b K d2 KG/PCS
10 - 14 14.5 4 90 16 60 14 0.7
  17.2 - 17.7 4 90 16 60 14 0.69
15 - 20 21 4 95 16 65 14 0.77
  21.3 - 22 4 95 16 65 14 0.77
20 - 25 26 4 105 18 75 14 1.06
  26.9 - 27.6 4 105 18 75 14 1.05
25 - 30 31 4 115 18 85 14 1.27
  33.7 - 34.4 4 115 18 85 14 1.25
32 - 38 39 4 140 18 100 18 1.86
  42.4 - 43.1 4 140 18 100 18 1.83
40 - 44.5 45.5 4 150 18 110 18 2.12
  48.3 - 49 4 150 18 110 18 2.09
50 - 57 58.1 4 165 20 125 18 2.78
  60.3 - 61.1 4 165 20 125 18 2.74
65 76.1 - 77.1 8 185 22 145 18 3.48
80 88.9 - 90.3 8 200 24 160 18 4.33
100 - 108 109.6 8 235 24 190 22 5.82
  114.3 - 115.9 8 235 24 190 22 5.61
125 - 133 134.8 8 270 26 220 26 7.91
  139.7 - 141.6 8 270 26 220 26 7.6
150 - 159 161.1 8 300 28 250 26 10.12
  168.3 - 170.5 8 300 28 250 26 9.58
175 193.7 - 196.1 12 350 32 295 30 14.45
200 219.1 - 221.8 12 375 34 320 30 16.9
250 - 267 270.2 12 450 38 385 33 27.28
  273 - 276.2 12 450 38 385 33 26.51
300 323.9 - 327.6 16 515 42 450 33 36.38
350 355.6 - 359.7 16 580 46 510 36 52.83
  - 368 372.2 16 580 46 510 36 50.24
400 406.4 - 411 16 660 50 585 39 74.71
  - 419 423.7 16 660 50 585 39 71.44
500 508 - 513.6 20 755 52 670 42 86.87
600 610 - 616.5 20 890 54 795 48 121.84
700 711 - 716 24 995 58 900 48 150.93
800 813 - 818 24 1140 64 1030 56 219.08
900 914 - 920 28 1250 70 1140 56 271.16
1000 1016 - 1022 28 1360 78 1250 56 344.95

Price List Of Spacer Blind Flanges
Stainless Steel Spacer Blind Flanges USD $2.07 - $10.08 / Piece (FOB Price) on request
High Nickel Alloys Spacer Blind Flanges USD $8.12 - $20.22 / Piece (FOB Price) on request
Duplex & Super Duplex Spacer Blind Flange USD $10.22 - $35.52 / Piece (FOB Price) on request
Cupro Nickel Spacer Blind Flanges USD $5.21 - $10.50 / Piece (FOB Price) on request
Carbon Steel Spacer Blind Flanges USD $2.10 - $7.12 / Piece (FOB Price) on request
Marking and Packing

Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All pipes are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.


  • Wooden Boxes
  • Wooden Pallets
  • Shrink-Wrapped
  • Carton Boxes
  • Wooden Boxes
  • Marking and Packing
    Quality Assurance
    Quality Assurance
