In the JIS b2220 Flanges, the complete form of ‘JIS’ is Japanese Industrial Standard. These are published by the Japanese Standards Association (JSA). These are similar to that of the USA’s ANSI. These BS 3293 Class 300 flanges, are manufactured from high-quality raw materials. Therefore, the bs 3293 flanges that are thus produced are of excellent quality. These bs 3293 standard welding neck flanges therefore also offer outstanding performance.
These BS 10 Blind Flanges have great features and attributes because of the elements that make up their chemical composition. Therefore, these British Standard BS 4504 flanges are utilised in many industries because of their applications. These PN40 BS 4504 SS Plate Flange undergo a series of tests in order to test and enhance their quality as well as performance. At every step, they are inspected and evaluated so that the product that is manufactured in the final phase is of high quality.
These PN40 BS 4504 SS Plate Flange could be available according to the needs as well as the requirements of the applications. These BS 3293 Class 150 flanges could also be manufactured according to the specifications that the client provides. Therefore, because of all the traits that these BS 4504 Flanges they offer excellent performance and are of high quality.
| Size: | 1/2"NB TO 24"NB IN |
| Class: | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN Standard ND-6,10, 16, 25, 40 Etc. |
| Materials: | Monel : Grade: Monel 400, Monel K500, Monel R-405 Nickel : Grade: Nickel 200, Nickel 201 Inconel : Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718 Incoloy : Grade: Incoloy 800, Inconel 800H, 800HT Hastalloy : Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X Titanium : Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11 Stainless Steel : Grade: ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L Carbon Steel : Grade: ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8 Duplex Steel: Grade: ASTM / JIS A/SA 182 UNS F44, F45, F51, F53, F55, F60, F61 Alloy Steel: Grade : ASTM A182 F1, F5, F9, F11, F22, F91 |
| Value Added Service: | CNC Machine, Customized Flanges |
| Coating/Surface Treatment: | Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
| BS Flanges Dimensions ‘DN’ (Nominal Diameter) in mm |
|||
|---|---|---|---|
| INCH | DN | INCH | DN |
| 1/2 | 15 | 12 | 300 |
| 3/4 | 20 | 14 | 350 |
| 1 | 25 | 15 | 375 |
| 1 1/4 | 32 | 16 | 400 |
| 1 1/2 | 40 | 18 | 450 |
| 2 | 50 | 20 | 500 |
| 2 1/2 | 65 | 24 | 600 |
| 3 | 80 | 28 | 700 |
| 4 | 100 | 30 | 750 |
| 5 | 125 | 32 | 800 |
| 8 | 200 | 36 | 900 |
| 10 | 250 | ||
| Standard | Class | Diameter of Bolt Circle | Dia. | Bolt Size | No. of Bolts | Bolt Hole Diameter |
|---|---|---|---|---|---|---|
| AS4087 | PN14 | 67 | 95 | M12 | 4 | 14 |
| JIS B16.5 | JIS 150 | 60 | 89 | 13 | 4 | 16 |
| JIS 300 | 67 | 95 | 13 | 4 | 16 | |
| JIS 600 | 67 | 95 | 13 | 4 | 16 | |
| JIS 900 | 83 | 121 | 19 | 4 | 22 | |
| JIS 1500 | 83 | 121 | 19 | 4 | 22 | |
| AS 2129 Flange | Table C | 67 | 95 | 13 | 4 | 14 |
| Table D | 67 | 95 | 13 | 4 | 14 | |
| Table E | 67 | 95 | 13 | 4 | 14 | |
| Table F | 67 | 95 | 13 | 4 | 14 | |
| Table H | 83 | 114 | 16 | 4 | 17 | |
| Table J | 83 | 114 | 16 | 4 | 17 | |
| ISO 7005 (DIN) Flange | PN6 | 55 | 80 | M10 | 4 | 11 |
| PN10 | 65 | 95 | M12 | 4 | 14 | |
| JIS | 65 | 95 | M12 | 4 | 14 | |
| PN20 | 60.5 | 90 | M14 | 4 | 16 | |
| PN25 | 65 | 95 | M12 | 4 | 14 | |
| PN40 | 65 | 95 | M12 | 4 | 14 |
Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All pipes are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.
At JF Engineering Products LLP, all fasteners are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.
Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
Delivery time and delivery dates are based on the "type and quantity" of steel ordered. Our sales team will provide a delivery schedule when quoting to you. On rare occasions the delivery schedule may change so please check with our sales department when placing any orders.
Orders will be sent out within 2-3 business days, and may take up to 5-10 business days in transit. If fastener is out of stock, orders may take up to 2-4 weeks to ship. JF Engineering Products LLP will notify buyer if this situation occurs.
