ANSI/ASME B16.9 Alloy 20 Pipe Fittings

Alloy 20 Reducer, Alloy 20 Elbow, Alloy 20 Tee, Alloy 20 Pipe Fittings, ASME B16.9 Buttweld Pipe Fittings, UNS NO8020 Buttweld Pipe Fittings, Alloy 20 pipe bend, Alloy 20 stub End, ANSI B16.9 Alloy 20 pipe fittings

Stainless Steel Tradename UNS no. Werkstoff No. Density (g/cm3)
Alloy 20 Incoloy Alloy 20, Carpenter 20 N08020 2.4660 8.083

Jfeindia is a company engaged in Alloy 20 Pipe Fittings production. In extreme environments too, the product has excellent stability. For production purposes, we use the best class raw material. Our products, therefore, have high demands for different industries, such as nuclear fuel processing plants or steel plants. The corrosion resistance properties of Alloy 20 Pipe Fittings are excellent. It can work at a high temperature without interruption. We have an easy-to-use production facility. For production purposes, our company uses excellent machining methods and processes. We promote the most advanced methods and techniques of production. Alloy 20 Tubes are made to work as a robust product with a remarkable tensile strength. With cryogenic temperatures, our produced product can work quickly. In each product, we check for different properties such as different chemical and physical elements. Through a series of tests, we derive different reports and conclusions. Our analysis promise chemical testing, detection of micro-macro-elements, and some other inspections. We believe that each product should have specific characteristics under national and international standards. jfeindia begins production only after a final raw material analysis has been carried out. Testing the physical and chemical properties of the raw material helps us to define the features of our finished product. We believe every product needs to have excellent mechanical characteristics. The raw material of Alloy 20 is of superior quality. This helps the end product to work under severe conditions of corrosion and cracking.

Alloy 20 Special Features:
  • Good Resistance to corrosion
  • Highly suitable for fabrication
  • Brilliant mechanical properties
Applications of Alloy 20 Pipe Fittings
  • Mixing Tanks
  • Chemical Plants
  • Dye production
  • Food Processing
  • Pickling Equipments
  • Petrochemical Plants

Key Properties of Alloy 20 Fittings | Flanges

  • Good resistance to corrosion, crevice corrosion, and pitting
  • Strong resistance to stress-corrosion cracking in boiling 20 to 40% sulfuric acid
  • Excellent resistance to other acids – phosphoric, and nitric acids
  • Highly suitable for fabrication
  • Excellent mechanical properties

Applications – Inconel Pipe Fittings and Flanges

  • Chemcal Plants
  • Food processing
  • Dye production
  • Heat exchangers
  • Mixing Tanks
  • Pickling equipments
  • Petrochemical plants

Alloy 20 Pipe Fittings Production Range

Specification ASTM B366, ASTM SB 366, ASTM B564, ASME SB564
Grade Alloy 20, UNS N08020, 2.4660, Incoloy Alloy 20, Carpenter 20
Type Seamless / Welded / Fabricated
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Range ½”NB to 24”NB in Sch 10s, 40s, 80s, 160s, XXS.
Dimensions ANSI/ASME B16.9, B16.28, MSS-SP-43.

Buttweld Alloy 20 Pipe Fittings

Seamless/ Welded 100% Radiography Tested

Products Size
Alloy 20 Elbows – Long Radius Alloy 20 Stub Ends Sizes 1/2″ – 24″
Alloy 20 Elbows – Short Radius Alloy 20 Crosses
Alloy 20 Reducing Elbows Alloy 20 Reducing Crosses
Alloy 20 45° Elbows Alloy 20 180° LR Return Bends
Alloy 20 Tees Alloy 20 180° SR Return Bends
Alloy 20 Reducing Tees Alloy 20 Pipe Bends / Piggable Bends
Alloy 20 Reducers Alloy 20 Couplings
Alloy 20 Concentric Reducers Alloy 20 Pipe Nipples
Alloy 20 Eccentric Reducers Alloy 20 Forged/Plate Cut Rings
Alloy 20 3D Elbow Alloy 20 End Caps
Alloy 20 5D Elbow Alloy 20 Forged / Plate Circles

High Pressure Forged Alloy 20 Pipe Fittings

Threaded and Socket Weld Pipe Fittings

Products Size
Alloy 20 90° Elbows Alloy 20 Couplings

Sizes 1/8″ – 4″

Pressure Ratings –
2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Alloy 20 45° Elbows Alloy 20 Reducers
Alloy 20 Street Elbows Alloy 20 Inserts
Alloy 20 Tees Alloy 20 Caps
Alloy 20 Crosses Alloy 20 Unions

Alloy 20 Flanges

Forged and Plate Flanges

UNS Grade UNS N08020
Standard ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size ½” to 36″
Dimensions ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Class / Pressure 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Product Size
Alloy 20 Slip-On Flanges Alloy 20 Threaded Flanges 1/2″ – 36″
Raised Face or Flat Face
Alloy 20 Weld Neck Flanges Alloy 20 Socket Weld Flanges
Alloy 20 Blind Flanges Alloy 20 Reducing Flanges
Alloy 20 Lap Joint Flanges Alloy 20 Plate Flanges

Marking & Packing

Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All fittings and flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.

Quality Assurance

At JF Engineering Products LLP, all fittings and flanges are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.

Test Certificates: Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
