Stainless Steel | Tradename | UNS no. | Werkstoff No. | Density (g/cm3) |
321 | 321 Stainless | S32100 | 1.4541 | 7.92 |
321H | 321H Stainless | S32109 | 1.4878 | 7.92 |
JF Engineering Products LLP is a leading maker and dealer of stainless steel 321/321H buttweld pipe fittings and 321/321H flanges, tee, reducer and bends. We have a complete stock of these stainless pipe fittings such as SS 321/321H elbow, SS 321/321H reducer, SS 321/321H Tee, SS 321 Cross, SS 321/321H Flanges and SS 321/321H Pipe Bends available according to the standard ASTM A403/ A182/ A240 and ANSI B16.9/16.28/ B16.25/ MSS SP-43.
Type 321 is similar to Type 304 Stainless steel but the only differene is the addition of titanium atleast five times the carbon content and titanium reduces carbide precipitation during welding. It is widely used in high temperature environments of upto 900 degree celcius. 321 stainless steel has amazing features such as good welding and forming capabilities. It is also known as UNS S32109 that provide higher temperature strength.
The key features of Stainless Steel 321/321H Pipe FittingsSpecification | ASTM A182 / A403 & ASME SA182 / SA403 |
Type | Seamless / Welded / Fabricated |
Variants | 321, 321H |
Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
Range | ½”NB to 48”NB in Sch 10s, 40s, 80s, 160s, XXS. |
Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
Seamless/ Welded 100% Radiography Tested
Products | Size | |
SS 321 Elbows – Long Radius | SS 321 Stub Ends |
Sizes 1/2″ – 48″ |
SS 321Elbows – Short Radius | SS 321 Crosses | |
SS 321 Reducing Elbows | SS 321 Reducing Crosses | |
SS 321 45° Elbows | SS 321 180° LR Return Bends | |
SS 321 Tees | SS 321 180° SR Return Bends | |
SS 321 Fabricated Tees | SS 321 Pipe Bends / Piggable Bends | |
SS 321 Reducers | SS 321 Couplings | |
SS 321 Concentric Reducers | SS 321 Pipe Nipples | |
SS 321 Eccentric Reducers | SS 321 Forged/Plate Cut Rings | |
SS 321 3D Elbow | SS 321 End Caps | |
SS 321 5D Elbow | SS 321 Forged / Plate Circles |
Threaded and Socket Weld Pipe Fittings
Products | Size | |
SS 321 90° Elbows | SS 321 Couplings |
Sizes 1/8″ – 4″ Pressure Ratings – |
SS 321 45° Elbows | SS 321 Reducers | |
SS 321 Street Elbows | SS 321 Inserts | |
SS 321 Tees | SS 321 Caps | |
SS 321 Crosses | SS 321 Unions |
Forged and Plate Flanges
Specification | ASTM A182 / A240 & ASME SA182 / SA240 |
Grade | 321, 321H |
Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
Size | 1/8” to 36″ |
Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
Product | Size | |
SS 321 Slip-On Flanges | SS 321 Threaded Flanges |
1/8″ – 36″ Raised Face or Flat Face |
SS 321 Weld Neck Flanges | SS 321 Socket Weld Flanges | |
SS 321 Blind Flanges | SS 321 Reducing Flanges | |
SS 321 Lap Joint Flanges | SS 321 Plate Flanges |
Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All fittings and flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.
At JF Engineering Products LLP, all fittings and flanges are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.
Test Certificates: Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
