Stainless Steel | Tradename | UNS no. | Werkstoff No. | Density (g/cm3) |
316 | 316 Stainless | S31600 | 1.4401 | 8.00 |
316L | 316L Stainless | S31603 | 1.4404 | 8.00 |
316H | 316H Stainless | S31609 | 1.4919 | 8.00 |
316Ti | 316Ti Stainless | S31635 | 1.4571 | 8.00 |
JF Engineering Products LLP is a leading maker and dealer of stainless steel 316/316L buttweld pipe fittings and 316/316L flanges, tee, reducer, and bends. We have a complete stock of these stainless pipe fittings such as SS 316/316L elbow, SS 316/316L reducer, SS 316/316L Tee, SS 316/316L Cross, SS 316/316L Flanges and SS 316/316L Pipe Bends available according to the standard ASTM A403/ A182/ A240 and ANSI B16.9/16.28/ B16.25/ MSS SP-43. 316/316L is a nickel and chromium stainless steel alloy with copper and molybdenum addition in it. It is particularly useful in severe corrosive conditions as it is non-magnetic and austenitic stainless steel. It offers brilliant resistance to oxidation and pitting. Pipe Fittings SS 316 /316L is ideal for many industrial processes that require a high resistance in harsh environments. These tubular fittings can withstand many acidic solvents, chemicals as well as chloride pitting. We are widely known for delivering products according to our esteemed customers' urgent requirements. We assemble SS 316 / 316L pipe connectors with premium quality that can withstand high pressure and temperature. For the fabrication of these pipe fittings, we select the premium quality raw material. These fittings are of excellent quality, such as perfect finish, durability, excellent pitting resistance, low maintenance, and robust construction. Jfeindia has an excellent production company for designing and developing superior Pipe Fittings SS 316/316L. During the testing and production phases, our expert team examines strictly SS 316/316L buttweld pipe fittings. By following all national and international standards, we manufacture dimensionally accurate pipe fittings. For finished and half-finished products, we have a proper storeroom. All quality testing steps are carried out under our quality controlling team.
The key features of Stainless Steel 316/316LSpecification | ASTM A182 / A403 & ASME SA182 / SA403 |
Type | Seamless / Welded / Fabricated |
Variants | 316, 316L, 316H, 316LN |
Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
Range | ½”NB to 48”NB in Sch 10s, 40s, 80s, 160s, XXS. |
Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
Seamless/ Welded 100% Radiography Tested
Products | Size | |
SS 316 Elbows – Long Radius | SS 316 Stub Ends |
Sizes 1/2″ – 48″ |
SS 316Elbows – Short Radius | SS 316 Crosses | |
SS 316 Reducing Elbows | SS 316 Reducing Crosses | |
SS 316 45° Elbows | SS 316 180° LR Return Bends | |
SS 316 Tees | SS 316 180° SR Return Bends | |
SS 316 Fabricated Tees | SS 316 Pipe Bends / Piggable Bends | |
SS 316 Reducers | SS 316 Couplings | |
SS 316 Concentric Reducers | SS 316 Pipe Nipples | |
SS 316 Eccentric Reducers | SS 316 Forged/Plate Cut Rings | |
SS 316 3D Elbow | SS 316 End Caps | |
SS 316 5D Elbow | SS 316 Forged / Plate Circles |
Product | Price/kg |
---|---|
SS 316 Elbows - Long Radius | 155 |
SS 316Elbows - Short Radius | 180 |
SS 316 Reducing Elbows | 156 |
SS 316 45° Elbows | 182 |
SS 316 Tees | 145 |
SS 316 Fabricated Tees | 153 |
Threaded and Socket Weld Pipe Fittings
Products | Size | |
SS 316 90° Elbows | SS 316 Couplings |
Sizes 1/8″ – 4″ Pressure Ratings – |
SS 316 45° Elbows | SS 316 Reducers | |
SS 316 Street Elbows | SS 316 Inserts | |
SS 316 Tees | SS 316 Caps | |
SS 316 Crosses | SS 316 Unions |
Forged and Plate Flanges
Specification | ASTM A182 / A240 & ASME SA182 / SA240 |
Grade | 316, 316L, 316H, 316LN |
Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
Size | 1/8” to 36″ |
Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
Product | Size | |
SS 316 Slip-On Flanges | SS 316 Threaded Flanges |
1/8″ – 36″ Raised Face or Flat Face |
SS 316 Weld Neck Flanges | SS 316 Socket Weld Flanges | |
SS 316 Blind Flanges | SS 316 Reducing Flanges | |
SS 316 Lap Joint Flanges | SS 316 Plate Flanges |
Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All fittings and flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.
At JF Engineering Products LLP, all fittings and flanges are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.
Test Certificates: Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection ReportSS 316 pipe fittings price list, stainless steel 316 buttweld fittings price, ss 316 pipe fittings manufacturer in mumbai, ss 316 long radius bend, pressure rating of stainless steel 316 pipe fittings, grade 316 stainless steel 180 deg long radius elbow,stainless steel aisi 316 pipe nipple distributor, din 1.4401 / 1.4436 pipe fittings, stainless steel 316l 90° long radius elbows stockist, stainless steel astm a403 wp316l fittings, ss 316l lap joint stub end stockholder, aisi 316l butt weld fittings, stainless steel wp316l butt weld long radius bend, asme sa403 stainless steel wp316 pipe fittings, 316 ss pipe fittings supplier in india, ss 316 pipe fitting manufacturer india, astm a403 wp 316l stainless steel long radius 45° elbows, uns s31600 pipe fittings, stainless steel 316l piggable bend, stainless steel 316 buttweld elbow price list india, stainless steel 316 pipe fittings manufacturers in india, astm a403 ss 316 pipe fittings in india, stainless steel 316 collar, 316l ss 90 deg short radius elbows dealers, ss S31603 pipe fittings, ss 316 buttweld fittings supplier in india, ss 316l straight crosses, astm a403 wp316 stainless steel 3d elbow., stainless steel 1.4404 / 1.4435 pipe fittings, stainless steel 316l pipe fittings exporter in india, ss 316 industrial pipe fittings
