JF Engineering Products LLP

Mild Steel Tube

Mild Tube Supplier Exporter Manufacturers and Stockist
We stock large quantities of the Mild Tube in both seamless & welded at all time in our stock house. We supply the material to all big and small parties at any time they need. We export the Mild Tube to all parts of the world. Our wide network and very good contact with supply chain managers enable us to deliver our products at any part of the globe. We provide a wide range of dimensions for the Mild Steel Tube and pipes so that they can fit to any size and shapes.

We ensure that the clients get the best product at the cheapest cost from us. We make sure that the order is delivered at the right time in the right place. We have built trust over the years for our best quality services and always look forward to build ling term business relationship with our clients. We are committed to quality and service. We are leading Mild Steel Tube suppliers in the industry. We Mild Steel Tube to all parts of the world. Our Mild Steel Tube are fabricated from the high quality raw materials. Hence they are very much durable.

Features :

  • High strength
  • High resistance to pitting, crevice corrosion resistance
  • High resistance to stress corrosion cracking, corrosion fatigue and erosion
  • Good sulfide stress corrosion resistance
  • Low thermal expansion and higher heat conductivity than austenitic steels
  • Good workability and weldability.
  • High energy absorption
  • Excellent finish
  • Durable

Specifications :

Size: 15mm NB to 150mm NB (1/2” to 6”), 7″ (193.7mm OD to 20″ 508mm OD)
Form Round, Square, Rectangular, Coil, U Tube,
Length As per customer’s requirement (Maximum upto 7 meters)
End Plain End, Bevelled End
Type Seamless / ERW / Welded
Certification For Mild Steel Mill Test Certificate as per EN 10204 / 3.2B
Dimensional Tolerances IS: 1239 (Pt I) – 2004, Equivalent to BS – 1387 / 1985
OD Range 1.250″ – 6.000″ (30-150mm)
Wall Range 0.095″ – 1.000″ (.2.5-25mm)

Dimensions :

Nominal Bore Outside Diameter Light (A-Class) Thickness Weight Medium (B-Class) Thickness Weight Heavy (C-Class) Thickness Weight
Inch mm Inch mm mm kg/mtr mm kg/mtr mm kg/mtr
1/8″ 3 mm 0.406 10.32 1.80 0.361 2.00 2.65 0.493
1/4″ 6 mm 0.532 13.49 1.80 0.517 2.35 0.407 2.90 0.769
3/8″ 10 mm 0.872 17.10 1.80 0.674 2.35 0.852 2.90 1.02
1/2″ 15 mm 0.844 21.43 2.00 0.952 2.65 1.122 3.25 1.45
3/4″ 20 mm 1.094 27.20 2.35 1.410 2.65 1.580 3.25 1.90
1″ 25 mm 1.312 33.80 2.65 2.010 3.25 2.440 4.05 2.97
1.1/4″ 32 mm 1.656 42.90 2.65 2.580 3.25 3.140 4.05 3.84
1.1/2″ 40 mm 1.906 48.40 2.90 3.250 3.25 3.610 4.05 4.43
2″ 50 mm 2.375 60.30 2.90 4.110 3.65 5.100 4.47 6.17
2.1/2″ 65 mm 3.004 76.20 3.25 5.840 3.65 6.610 4.47 7.90
3″ 80 mm 3.500 88.90 3.25 6.810 4.05 8.470 4.85 10.1
4″ 100 mm 4.500 114.30 3.65 9.890 4.50 12.10 5.40 14.4
5″ 125 mm 5.500 139.70 4.85 16.20 5.40 17.8
6″ 150 mm 6.500 165.10 4.85 19.20 5.40 21.2

Applications :

  • Use in Heat Exchangers
  • Use in Instrumentation
  • Use in Hydraulic & Pneumatic system
  • Use in Nuclear Power Plants
  • Use in Automotive industries
  • Use in Aerospace
  • Use in Medical
  • Use in Pharmaceutical
  • Use in Oil coolers
  • Use in Economizers
  • Use in Condenser
  • Use in LNGs
  • Use in Pulp and paper
  • Use in Offshore construction

We have long experience in the business of manufacturers of Mild Steel Tubes. We have established state of the art manufacturing facilities and have the best technology available for the manufacturing process along with the best technical staff. Our raw materials are selected and purchased after a vigorous quality control check has been done by our research team. So having all these factors on our sides we ensure that all our clients whether small business owners or big parties should get the best possible deal from us . We strive to build excellent professional relationship with all our clients. Our objective is to provide excellent services to our clients. We understand that for our vision of growth we have to deliver the best quality Tubing Products and services consistently. Our constant endeavor is to excel in all the aspects of manufacturing, packaging, shipment and export of the Mild Steel Tube.
